Tech“In a hydraulic valve lifter, a check valve allows engine oil to flow into the lifter's high-pressure chamber but prevents the oil from flowing back out when the camshaft lobe loads the lifter to open the engine valve.”
Submitted by Brave Wren 909b
The conclusion
Open in workbench →The claim accurately describes the standard operating principle of a hydraulic valve lifter. Authoritative technical sources agree that the check valve admits oil into the high-pressure chamber and closes under cam load to prevent reverse flow through that valve during valve opening. Real lifters can still bleed down through clearances, but that does not make the core description incorrect.
Caveats
- Hydraulic lifters are not perfectly sealed in practice; some controlled leak-down occurs through plunger-to-bore clearances, not back through the check valve.
- A worn, dirty, or faulty check valve can fail to hold pressure, but that is an abnormal condition rather than the normal mechanism described here.
- Some informal sources say the oil is 'compressed'; the more accurate explanation is hydraulic locking with minor compliance from clearances and leakage, not meaningful bulk oil compression.
Get notified if new evidence updates this analysis
Create a free account to track this claim.
Sources
Sources used in the analysis
In the internal architecture description, the guide defines the check valve as: "Check Valve (Ball or Disc): Permits inflow of oil and prevents reverse flow during lift." It then explains the operating sequence: during the fill phase, "Oil enters through the feed hole and opens the check valve." During the load phase, "The cam lobe begins applying upward force on the lifter body. The check valve closes and traps oil in the chamber. The trapped oil forms an incompressible hydraulic column. Lift transfers directly to the pushrod or rocker." In the reset phase, as load is removed, internal pressure drops and "the check valve" reopens so the chamber can refill.
The article states: "The tappet has a reservoir oil chamber and high pressure oil chamber separated by a check valve ball and spring." It describes the base-circle phase: "When the lobe of the camshaft isn’t applying pressure to the tappet (the camshaft is on its base circle) oil can flow between the two chambers and exit the reservoir chamber to allow the tappet to compress against its check valve spring if needed." It then describes what happens under cam load: "The cam lobe applies pressure to the tappet when it is time for the valve to be opened. This forces the check valve closed and seals the high pressure oil chamber making the tappet rigid so it can transfer the motion of the camshaft to the valve. The check valve opens and the tappet becomes pliant again when the valve closes and the tappet returns to its resting position."
Describing the internal parts, the article notes: "The hydraulic lifter consists of a cylindrical housing and a plunger backed by a spring at the top and a check valve at the bottom." It explains that when the cam lobe pushes the tappet up, "the spring is depressed allowing oil to flow into the lifter. Since oil is not compressible, the lifter is then solid and the valve is opened as the top of the cam lobe rotates upward." As the cam lobe rotates away and the lifter is lowered, "the spring pressure is relaxed. This allows the check valve to open again so the valve can fully close." The discussion of leaky check valves implies that when functioning correctly they seal the oil during lift, keeping the lifter solid.
“When the lifter rides on the cam's base circle, **oil fills the internal cavity and raises the piston**. As the lobe lifts, **a check valve traps the oil, making the lifter act solid so it can open the valve**. Once the lobe passes its peak, pressure drops, fresh oil refills the chamber, and the cycle repeats smoothly and quietly.”
“A **hydraulic lifter uses engine oil pressure to fill a small internal piston**… At the heart of a hydraulic lifter is a small piston that sits between the camshaft lobe and the valve stem. **This piston is filled with engine oil, which acts as a hydraulic fluid. As the camshaft lobe pushes against the hydraulic lifter, the oil inside is compressed** which compensates for valve lash as the lifter rises and opens the valve. When the camshaft lobe passes and the valve spring pushes the valve closed, the hydraulic lifter retracts back to its initial position. The constant supply of pressurized oil keeps the lifter adjusted perfectly….”
In a cutaway explanation of a hydraulic lifter, the presenter shows the internal piston and says: “That piston gets oil as it comes through this hole and it fills up that cavity and **at the bottom of our piston it's got a tiny little hole in there with a check ball and a spring**… when everything's at rest my ball is pushed up by the spring and it closes that hole. **When the oil pressure gets high enough it pushes the ball off the seat and it allows the oil that's inside this piston to come down here underneath that piston in this cavity**… when that pushrod tries to push down now it's not just pushing against a spring, **it's pushing against this hydraulic lock that we've made by filling that thing with oil**.”
“Oil from the engine’s lifter gallery enters the lifter body and is metered through a small orifice and CHECK VALVE into the high‑pressure chamber under the plunger. On the base circle of the camshaft, this check valve is open and the chamber fills. When cam lobe lift is applied, the check valve closes and the oil is trapped beneath the plunger so it cannot bleed back into the body during the lift event. This trapped oil makes the lifter behave like a solid piece until the load is removed.”
One technical explanation on the forum states: "The oil enters the lifter from block oil passages under pump pressure while the lifter’s on the cam’s base circle, with near zero valve spring pressure on the lifter so the plunger can move." It continues: "Once the cam lobe starts to lift the lifter, the check valve closes and traps oil under the plunger, effectively making the lifter a solid piece for that part of the cycle." The poster notes that any bleed-down occurs through controlled leakage paths rather than back through the check valve during lift.
Standard automotive engineering textbooks describe a hydraulic valve lifter (hydraulic tappet) as having a low-pressure reservoir and a high-pressure chamber separated by a spring-loaded check valve or disc. Oil is supplied from the engine oil gallery and flows through the check valve into the high-pressure chamber when the lifter is on the camshaft base circle. When the cam lobe raises the lifter to open the engine valve, the internal pressure increase forces the check valve to close, trapping oil in the high-pressure chamber so the lifter behaves as a solid body. Any necessary leak-down occurs through controlled clearances rather than reverse flow through the check valve during lift.
In the technical walkthrough (around 2:35–3:20), the presenter describes oil flow and the check valve: engine oil pressure fills the plunger cavity and the chamber below it, "some of it will come down through the check valve and fill up this chamber down below the plunger." He then explains: "As soon as the lifter body tries to lift up, that's going to push the push rod down onto the plunger and then create a hydraulic lock and that's created by this check valve… that check valve closes off just the slightest bit of movement… all the oil that's built up in here, it's locked in there… that lifter is now a solid lifter and it opens up your valve." Later he notes that bleed-off occurs through clearance between plunger and body, not through the check valve during lift.
Describing the internal mechanism, the article notes that hydraulic lifters use a plunger and a one-way valve: engine oil flows into the plunger cavity when the lifter is on the cam's base circle to take up clearance. When the cam lobe comes around and load is applied, the one-way (check) valve closes, trapping oil under the plunger so the lifter becomes effectively solid and can transmit cam lift to the valve. The one-way valve is designed so that oil can enter to adjust lash but cannot flow back out during the high-pressure lift portion of the cycle.
Discussing why a solid lifter is used for checking cam timing, the thread notes that a hydraulic lifter's internal mechanism compresses under load: “as the cam rotates it **compresses the lifter seat** as the lobe acceleration ramp… the hydraulic lifter can bleed down due to its internal oil system and check valve action, affecting accurate lift readings.” This reflects that the **check valve and internal oil chamber normally support the lifter under running conditions**, but their hydraulic behavior complicates measurement.
A detailed post on disassembling a VW hydraulic lifter lists the internal parts: "valve body and from the bottom up are the plunger spring, plunger assembly (ball check valve, check valve spring, check valve retainer not shown), metering disk, pushrod socket and lock ring." When refilling the lifter, the author explains that you depress the ball check valve to allow air and oil to escape while lowering the plunger, showing that the ball acts as a one‑way valve for fluid into and out of the lower cavity during service. Another contributor notes that in operation "there is a constant bleed-off of oil from the lower cavity out along the gap between the plunger and the bore, which is replenished by oil being admitted by the ball valve when there is any slack in the valvetrain," indicating that normal bleed is via plunger clearance while the check valve primarily controls inflow and locks the chamber during lift.
Summit explains: “In a hydraulic lifter, **engine oil fills the plunger cavity through a small orifice and check valve** when the lifter is on the camshaft base circle. As the cam lobe lifts the lifter, **the check valve closes, trapping oil under the plunger so it cannot bleed out during the lift**. This hydraulic lock lets the lifter act as a solid part to open the valve while still taking up lash when the load is removed.”
